IM 3000

Product Specification

Specification

Model

Model	IM 3000

Configuration

Functions	Copy, print, scan, optional fax
Colour	Yes
HDD	320GB
Memory - Standard	2 GB
Memory - Optional	4 GB—maximum 4 GB
Operation Panel	10.1-inch tilting colour WSVGA Smart Operation Panel

Physical Dimensions

Physical Dimensions	587 x 685 x 788 mm
Weight - Mainframe	82.5 kg or less

Media Handling

Standard Input Capacity (sheets)	1,200
Maximum Input Capacity (sheets)	2,300
Standard Output Capacity (sheets)	500 250—B4 or larger
Maximum Output Capacity (sheets)	1,625
Paper Input Configuration - Standard	2 x 550-sheet paper trays, 100-sheet bypass tray, duplex unit
Paper Output Configuration - Standard	500-sheet face-down internal output tray
Supported Media	Tray 1 Plain paper, recycled paper, special paper 1–3, colour paper, letterhead, cardstock, pre-printed paper, bond paper, glossy coated paper, coated paper, normal paper, middle thick, thick paper 1, thick paper 2, thick paper 3, thick paper 4 Tray 2 Plain paper, recycled paper, special paper 1–3, colour paper, letterhead, cardstock, pre-printed paper, bond paper, glossy coated paper, coated paper, envelopes, normal paper, middle thick, thick paper 1, thick paper 2, thick paper 3, thick paper 4 Paper banks Plain paper, recycled paper, special paper 1–3, colour paper, letterhead, cardstock, pre-printed paper, bond paper, glossy coated paper, coated paper, envelopes, normal paper, middle thick, thick paper 1, thick paper 2, thick paper 3, thick paper 4 Bypass tray Plain paper, recycled paper, special paper 1–3, colour paper, letterhead, cardstock, pre-printed paper, bond paper, glossy coated paper, coated paper, envelopes, label paper, OHP, thin paper, normal paper, middle thick, thick paper 1, thick paper 2, thick paper 3, thick paper 4
Maximum Paper Size	SRA3
Media Weight (g/m²)	52–300

Connectivity

Interface - Standard	Mainframe 10Base-T/100Base-Tx (Ethernet) 1000Base-T (Gigabit Ethernet) USB Host Type A—2 ports USB Type B—1 port Smart Operation Panel IEEE 802.11 b/g/n (Wireless LAN)¹ Bluetooth² SD card slot—SDHC memory card USB Host Type A—USB Flash memory USB Host Type A—1 port for USB keyboard² USB Host Type mini B—for NFC card reader² microSD card slot—ROM storage expansion² NFC tag² ¹—Limited printing for a peer-to-peer mobile device via RICOH Smart Device Connector ²—Cannot be used for printing
Interface - Optional	IEEE 1284/ECP IEEE 802.11a/g/n (Wireless LAN) USB device server (additional Ethernet/Gigabit Ethernet port)
Network Protocols - Standard	TCP/IP (IPv4, IPv6)

Copy Features

Copy Speed	30 cpm
First Copy Time	5.1 seconds—black and white 7.4 seconds—colour
Copy Resolution	600 x 600 dpi—4-bit Note: Copy resolution when scanning
Zoom Range	25%–400% in 1% steps
Enlargement Ratios	115%, 122%, 141%, 200%, 400%
Reduction Ratios	93%, 82%, 75%, 71%, 65%, 50%, 25%
Duplex Copy	Simplex to duplex, duplex to duplex—with ARDF, book to duplex, front and back to duplex
Book Copy	Booklet, magazine, layout and booklet
ID Card Copy	Supported
User Codes	1,000 user codes

Print Features

Print Speed Colour	30 ppm
Print speed Black and White	30 ppm
First Print Time	5.5 seconds black and white, 7.7 seconds colour
Print Resolution	1,200 x 1,200 dpi—2-bit Note: Print speed will be slower when printing at 1,200 x 1,200 dpi
Page Description Languages (PDLs)	Standard PCL 5c, PCL 6, PostScript 3 emulation, PDF Direct emulation Optional Genuine Adobe PostScript 3, PDF Direct from Adobe, XPS Direct Print, PictBridge
Printer Drivers	Standard PCL 5c, PCL 6, PostScript 3 emulation Optional Genuine Adobe PostScript 3
Duplex Printing	Standard
Mobile Printing	Yes
Print From USB/SD	Supported

Scan Features

Scan Speed	80 ppm—via ARDF Via SPDF 120 ppm—single-sided, 200 x 200 dpi 110 ppm—single-sided, 300 x 300 dpi 240 ppm—duplex, 200 x 200 dpi 180 ppm—duplex, 300 x 300 dpi
Scan Methods	Scan to USB/SD, Scan to email, Scan to webmail, Scan to folder (SMB, FTP), Scan to URL, Scan to PDF/A, Scan to searchable PDF Note: Optional OCR unit is required to support scanning to a searchable PDF
Colour Scanning	Standard
Scan Resolution	100 x 100 dpi, 200 x 200 dpi, 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi, 1,200 x 1,200 dpi; default 200 x 200 dpi
Scan to File Types	Single- and multi-page TIFF Single-page JPEG Single- and multi-page PDF, PDF/A Single- and multi-page high-compression PDF
Scan to Email	Protocols SMTP gateway, TCP/IP, POP, IMAP 4 Authentication SMTP authentication, POP before SMTP authentication Scan resolution 100 x 100 dpi, 200 x 200 dpi, 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi; default 200 x 200 dpi Scan to email file types Single-page TIFF, JPEG, PDF, PDF/A, high-compression PDF, encrypted PDF, searchable PDF Multi-page TIFF, PDF, PDF/A, high-compression PDF, encrypted PDF, searchable PDF Note: Optional OCR unit is required to support scanning to a searchable PDF
Scan to Folder	Protocols SMB, FTP Security Client folder logon, transmission encryption of logon name and password Resolution 100 x 100 dpi, 200 x 200 dpi, 300 x 300 dpi, 400 x 400 dpi, 600 x 600 dpi; default 200 x 200 dpi Search for client folders SMB—browsing directly to the designated folder FTP—by folder name Scan to folder file types Single-page TIFF, JPEG, PDF, PDF/A, high-compression PDF, encrypted PDF, searchable PDF Multi-page TIFF, PDF, PDF/A, high-compression PDF, encrypted PDF, searchable PDF Note: Optional OCR unit is required to support scanning to a searchable PDF
TWAIN Scanning	Scan mode Standard, Photo, OCR, Filing Scan resolution 100 x 100 dpi–1,200 x 1,200 dpi

Fax Features

Fax Types	G3 fax, Internet fax (T.37), IP fax (T.38), LAN-Fax, Paperless fax, Direct SMTP fax
Fax Circuit	PSTN, PBX
Fax Compatibilty	ITU-T (CCITT), G3—maximum 3 lines
Fax Modem Speed	2,400 bps–33.6 Kbps—G3, standard with automatic shift down
Fax Compression Speed	MH, MR, MMR, JBIG
Fax Resolution	Standard mode 200 x 100 dpi—8 x 3.85 lines/mm Detail mode 200 x 200 dpi—8 x 7.7 lines/mm Super fine mode 400 x 400 dpi—8 x 15.4 lines/mm 400 x 400 dpi—16 x 15.4 lines/mm Note: Super fine mode is supported with the optional SAF memory
G3 Fax Transmission Speed	2 seconds approximately—JBIG, ITU-T No. 1 chart, TTI off, memory transmission 3 seconds approximately—MMR, ITU-T No. 1 chart, TTI off, memory transmission
Fax SAF Memory Capacity	Standard 4 MB—approximately 320 pages With optional SAF memory 60 MB—approximately 4,800 pages
Fax Memory Backup	1 hour
Quick Dials	2,000 numbers

Security Features

Data Overwrite Security System (DOSS) - Standard	Yes
Encryption	HDD, AES 256-bit, SSH, SHA-2, PDF, Secure print, WEP, WPA Authentication password Encryption of data sent via Scan to email and Fax forwarding (S/MIME)
Authentication	802.1x wired authentication Administrator authentication IEEE 802.11i security (WPA2) IPv6 Quota setting User authentication—Windows and LDAP via Kerberos, basic, user code WiFi Protected Setup (WPS) support

Supported Operating System

Windows	PCL 5c, PCL 6, and PostScript 3 Windows Server 2008 Windows Server 2008 R2 Windows 7 Windows 8.1 Windows Server 2012 Windows Server 2012 R2 Windows 10 Windows Server 2016
Macintosh	OS X Native v10.11 or later—PostScript 3 only
Unix	Sun Solaris—10 HP-UX—11.x, 11iv2, 11iv3 Red Hat Linux—Enterprise, 4.x, 5.x, 6.x SCO OpenServer—5.0.7, 6.0 IBM AIX— 6.1, 7.1, 7.2
SAP	Environment—R/3, S/4 SAP R/3 Device Type—supported Barcode fonts—Code 128, Code 39, Code 93, Codabar, 2 of 5 interleaved/Industrial/Matrix, MSI, USPS, UPC/EAN OCR fonts—OCR A, OCR B

Software and Solutions

Standard	@Remote Embedded Web Image Monitor
Optional	@Remote Office @Remote Enterprise Pro Java SDK Card Authentication Package Device Software Manager Device Manager NX Enhanced Locked Print NX GlobalScan NX Printer Driver Packager NX Streamline NX
Mobile Apps	Smart Device Connector

Environmental Features

Power Source	220–240 V, 50/60 Hz—Asia Pacific 110 V, 60 Hz—Taiwan
Power Consumption	1,700 W or less—maximum power, Asia Pacific 1,584 W or less—maximum power, Taiwan 415.9 W—operating power, black and white 465.2 W—operating power, colour 46.2 W—Ready Mode 0.55 W—Energy Saver Mode (Sleep Mode)
Typical Electricity Consumption (TEC)	0.7 kWh
Warm-up Time	21 seconds or less—Quick Mode from main switch
Power Saving Mode	1 minute shift time—Energy Saver Mode (Sleep Mode)
Recovery Time	From Energy Saver Mode 0.5 seconds—to Key Operation Ready Mode 6.1 seconds—without Human detection sensor, Asia Pacific 6.6 seconds—without Human detection sensor, Taiwan
Green Labels	The Thai Green Label Scheme, Blue Angel Mark (BAM)
Other Environmental Features	Eco-friendly indicator, On/off timer, Remote Power Off, Default duplex printing, Eco counter, Human detection sensor
